Online SOX Gas Analyzer

Online SOX Gas Analyzer

Send Inquiry

With years of experience and knowledge in this domain, we are engaged in offering an excellent range of Online SOx Gas Analyser. This analyzer is thoroughly manufactured at our advanced manufacturing unit using the best quality raw material and innovative technology in observance with defined quality standards. This analyzer is used to clean and dry the gas sample for accurate and high performance operation. Being a quality-oriented organization, we assure our clients that this analyzer is excellent on counts of durability and quality.

Features:

  • Compact design.
  • Easy to operate.
  • Superior performance.


Other Details:

  •  ATS- 208A Emission Analyzer continuously monitors the concentration of SOX ,SO2 PPM level. Feature includes a duel wavelength sensor, Remote Sampling, Graphics LCD Display, adjustable level relay output for alarm and 4-20mA output for control purpose and minimal maintenance.
  • Special gas sample Conditioning systems are used to clean and dry the gas sample for accurate and High performance operation. An Internal Pump draw gas sample into the sensor through a dust particle filter from an intake which can be located at distance up to 40 meter form the monitor.
  • The Sensor and Electronic component are housed in tough aluminium housing.
  • Microcontroller based embedded intelligent instruments.
  • Continuous Monitoring of SO2 & SOX.
  • Duel wavelength Infra red sensor for Long terms accuracy and stability.
  • Long Life Electrochemical sensor.
  • Six Gas Analysis in Single Analyser.
  • Multi Parameter Single 320 X 240 Graphics LCD Display.
  • Self diagnostic & Self integrity check.
  • RS 232/RS 485 and USB Computer Interface.
  • Excellent low level capability for NOX and SO2 Measurement.
  • For most of the application sample gas is cooled and dried inside the sampling conditioning systems to avoid the Heated Sample Line.
