Fixed Ammonia Gas Detection System

Fixed Ammonia Gas Detection System
Fixed Ammonia Gas Detection System
Product Code : ATS 105M
25500 - 35500 INR
Price And Quantity
Minimum Order Quantity :
1
Unit of Measure :
Pack/Packs
Price Range :
25500 - 35500 INR
Product Specifications
Usage :
Gas Leak Monitoring
Dimensions :
115(H) X180(L) X 60(D) Millimeter (mm)
Power :
230 Watt/Volt ( w/v)
Product Description

Gas Transmitter: ATS-109TD


Following industry defined guidelines, we manufacture this detector by utilizing contemporary machines, modernize technology and best grade material. In order to ensure quality, the entire array is rigorously tested upon a series of parameters. It is easy to install, designed for wall mounting and completely programmable from the front panel membrane switches. Apart from this, we offer the entire range in a wide array of specifications as per the diverse requirements of our clients.


Features:

  • Low maintenance cost
  • Non corrosive body
  • Other Details:

    • Model ATS-105M is Single channel Ammonia gas Monitor for environmental Monitoring and Leak detection.
    • The ATS-105M is an economical, yet versatile Multi channel controller with the features needed for monitoring a remote 4-20 mA gas sensor/transmitter or similar device.
    • The instrument provides 24 VDC power, audio/visual alarms, alarm relays and other features.
    • The ATS-105M is easy to install, designed for wall mounting and completely programmable from the front panel membrane switches.
    • Accept Multi 4-20 mA Input from Remote Sensor/Transmitter.

    Ammonia Gas Tranmsitter
    The ATS-109TD Sensor/Transmitter with without Display operates on 24 VDC power and 4-20 mA output and optional alarm relay board. This sensor/transmitter can be connected to various applied controllers or computer-based instrumentation, such as PLC or similar instrumentation.

    The ATS-109TD Ammonia (NH3) Sensor/Transmitters utilize electrochemical type cells to detect the target gas. These cells consist of electrodes, electrolyte and an air/liquid separation barrier. Gas molecules enter the cell and, as a result of an oxidation/reduction reaction, generate an electrical current proportional to the gas concentration


    Specifications:

    Principle: Electrochemical, Solid State Semiconductor Catalytic and PID.

    • Range: PPM/PPB or mg/M3.
    • Resolution: 0.1 Unit or 1 Unit (Application based)
    • Sampling Method: Diffusion
    • Display: 128 X 64 Graphics LCD
    • Alarm; Relay Contact NO+NC
    • Anolog out Put: 4-20mA
    • Digital out Put: RS 232, RS 485 and Modbus Communication Protocol
    • Power Source: 230V AC
    • Accuracy: +/2%
    • Response Time: Data Storage: 1000 or 10000
    • Sensor Life: 2-3 Years

    Environmental:

    Temperature:-15 degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86- 106Kpa

    • Dimension in mm: 210 (W) X 180(H) X 110(D)
    • Weight: 1.2 KG
    • Warranty: One Year
